RW90 2/0 BLK Copper Wire

Copper conductors, XLPE insulation, sunlight resistant, 1000 V, 90 °C Max, -40 °C Min, Gasoline and oil resistant. Suitable for installation in cable trays, underground duct banks, for grounding and bonding applications. Class B compressed stranded bare copper per ASTM B3 and ASTM B8 conductor, Cross Linked Polyethylene (XLPE) insulation.

Category:

Description

  • Wire Gauge Size – 2/0 AWG
  • Number of Conductors – 1
  • Stranded/Solid – Stranded
  • Number of Strands – 19
  • Conductor Material – Copper
  • Insulation Material – XLPE
  • Jacket Color – Black
  • Voltage Rating – 600 V
  • Outside Diameter – 13.16 mm
  • Insulation Thickness – 1.4 mm
  • Amperage Rating 185 – 285 A
  • Temperature Rating – -40 to 90 °C
